Gateron Optical Switch (Version 2)
Gateron Optical Switch (Version 2) - Blue / 110 Switches is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Newly Upgraded Structure
The Gateron KS-22 Optical switch is crafted with a transparent cover and black base. As an upgraded version of the KS-15 switches, we designed the KS-22 switches with a new structure and a more stable, smooth hand feel. Unlike a mechanical switch, an optical switch uses light for actuation instead of a metal-to-metal connection, enhancing the trigger speed over mechanical switches.
![](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateronks22opticalswitches1657261248335--edited-1659432191744-1661940452417_1200x.jpg?v=1661940454)
Enlarged Light-Transmitting Opening
Compared to the first-generation optical switch, we enlarged the Gateron KS-22 Optical Switch's light-transmitting opening to increase the switch's operational lifespan to 100 million.
![Inside Gateron Optical Brown Switch](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-ks22-optical-switches-1655887018632-1661940506309_1200x.jpg?v=1661940508)
New Waterproof Design Concept
These optical switches will introduce a new waterproof design concept that protects its body from water.
Factory Pre-Lubed
The Gateron KS-22 Optical Switch is lightly pre-lubed in the factory to offer a smooth and tactile typing experience, just like the mechanical switch.
Note: Optical Blue Switch are unlubed.
![Gateron Optical Switches](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-ks22-optical-switches2-1657260767222-1661941376651_1200x.jpg?v=1661941378)
How They Work
The infrared optical sensing component uses light-sensing principles to generate different but equivalent resistance to form two states of open circuits and paths, thereby triggering the key signal command.
![Gateron Optical Brown Switch](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/gateron-ks22-optical-switches2-1655887077945-1661940813816_1200x.jpg?v=1661940815)
Features
![Different Gateron KS-22 Optical Switches Features Different Gateron KS-22 Optical Switches Features](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/pf4508ebdegateronopticalswitchfeaturechart1655283024253-1659431634483-1661940854751_1200x.jpg?v=1661940856)
Specs
Product Name | Gateron KS-22 Optical Switch |
---|---|
Stem | POM, MX stem |
Housing | PC (Cover), Nylon PA66 (Base) |
Spring | Stainless steel |
Pins | No |
Lubrication | Pre-lubed (Red, Brown) |
SMD LED support | Yes |
Compatible Keyboards
No pins on the switches, compatible with K8 keyboard Gateron Optical version.
![Gateron KS-3 Full Black Switches Layout of PCB Gateron KS-3 Full Black Switches Layout of PCB](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/structure-diagram-1655800073249-1661941018960_1200x.jpg?v=1661941020)
![Gateron KS-3 Full Black Switches Layout of PCB Gateron KS-3 Full Black Switches Layout of PCB](https://cdn.shopify.com/s/files/1/0568/8514/9779/t/3/assets/structurediagram21660011302821-1660030541417-1661941069285_1200x.jpg?v=1661941070)
Note: Gateron optical switch cannot be compatible with regular mechanical keyboards.
