Collezione di layout ISO di tastiere meccaniche personalizzate wireless Keychron K1 Pro QMK/VIA

Keychron K1 Pro
ISO Layout Collection

The Keychron K1 Pro is a 80% layout low profile wireless mechanical keyboard with QMK/VIA enabled for endless possibilities.

Fully Assembled-PBT Keycaps Version (Non-Shine-Through)

Fully Assembled-ABS Keycaps Version (Shine-Through)

*Fully Assembled-ABS Keycaps Version features LSA Shine-through ABS keycaps.
*Fully Assembled-PBT Keycaps Version features LSA double-shot PBT keycaps, which are non-shine-through.

Wireless and Wired

An excellent solution for multitasking. Connects the K1 Pro with up to 3 devices wirelessly via its stable Broadcom Bluetooth 5.1 for seamless multitasking across your laptop, phone, and tablet. Switch among them swiftly, and it’s fully compatible with both Mac and Windows.

You can also enjoy a USB Type-C wired connection with 1000 Hz polling rate which is engineered for the competitive game.

Ultra-Slim

The innovative low-profile Gateron switch is 31% slimmer than conventional normal profile switches makes the aluminum body K1 Pro one of the thinnest wireless mechanical keyboards in the world. While still delivering a distinguished tactile response.

Program with QMK & VIA.

QMK/VIA means endless possibilities for a fluid workflow. Thanks to our engineering team, it's the first time in history that a wireless mechanical keyboard has these kinds of capabilities right out of the box.

Simply connect the K1 Pro to your device with a cable, drag and drop your favorite keys or macro commands to remap any key you want on any system (macOS, Windows, or Linux).

Check out the video above demonstrating how to remap the Light Effect key (located on the K1 Pro’s top right corner) to an Eject key with the VIA software, so you can get a shortcut to put your Mac to sleep (Command-Option-Eject), or even remap the fn key in a breeze. It’s never been so intuitive and flexible to personalize your own keymap.

An ultra-low-power ARM Cortex-M4 32-bit STM32L432 MCU which is powerful, and equipped with 128K Flash will provide more flexibility for developers.

Get the keymap working on VIA

Since the VIA code for the K1 Pro ISO is still awaiting approval from Github, it is not yet automatically recognized, so you will need to manually download and import the K1 Pro keymap.

Please download the keymap JSON file below. Connect your keyboard and device with the provided cable, and toggle the switch to cable mode. Open VIA, click on the "Show Design tab" on the "Settings" tab, and drag the JSON file into the “Design” tab on VIA to get the K1 Pro keymap working on VIA.

K1 Pro Keymap JSON Files

An Epic Core Inside

A powerful ultra-low-power ARM architecture MCU equipped with 128K Flash will provide more flexibility for developers. The polling rate is 1000 Hz on wired mode right out of the box, which makes the latency hardly noticeable even in competitive games.

Hot-swappable

We all have our unique typing preferences, that’s why we are offering hot-swappable option on the K1 Pro, so you can easily hot-swap every low-profile Gateron mechanical switch in a few seconds to customize the typing experience without soldering.

*The K1 Pro is currently compatible with Gateron low-profile mechanical switches only, as QMK does NOT support low-profile optical switches.

RGB Backlights

Comes with more than 22 types of RGB backlight settings (as well as a static white backlight option). You can further fine-tune the RGB hue, saturation, brightness, effect speed with ease.

The Gateron low-profile MX 2.0 Mechanical switch is designed to enhance reliability. Gateron's reputable switches are your best choice for a precise, smooth, and reliable fingertip feel whether you prefer linear (red), clicky (blue), or something in between (brown).

Ergonomic Support

Three levels of adjustable typing angle aim to provide long-lasting ergonomic wrist support.

What's in the box?

Select the matching variant for your product.

Layout Difference
